Innovative Environmental Wireless LoRaWAN NH3 Sensor

Innovative Environmental Wireless LoRaWAN NH3 Sensor

xiamen ZoneWu LoRaWAN NH3 sensor is an innovative IoT sensing device built with LoRa wireless technology. Its integrated ammonia, temperature and humidity sensors can measure the ammonia concentration, temperature and humidity in the environment in real time, with the characteristics of high sensitivity, high precision and high stability.

  • Product Model :

    LW300-NH3
  • Power Supply Mode :

    Battery or External DC
  • Frequency :

    CN470/IN865/EU868/RU864/US915/AU915/ KR920/AS923-1&2&3&4
  • MAC Version :

    LoRaWAN 1.0.3
  • Mode :

    OTAA Class A/C
  • Weight :

    120g

Innovative Environmental Wireless LoRaWAN NH3 Sensor



xiamen ZoneWu LoRaWAN NH3 sensor is excellent, capable of collecting ammonia data in the environment, real-time monitoring of ammonia concentration dynamics, and realizing data transmission. As a wireless gas sensor, it is suitable for IoT application scenarios.



xiamen ZoneWu LoRaWAN Gas Sensor NH3 Sensor Features:



LoRaWAN ammonia sensor is a wireless IoT gas sensor that can collect, monitor and transmit data, mainly used to detect ammonia in the environment.



It contains an ammonia sensor, a two- or three-electrode electrochemical sensor, and a high-performance microprocessor.



High sensitivity, high resolution, good stability, and strong interference resistance.



It supports the standard LoRaWAN protocol, enabling long-distance communication and convenient data transmission.



It can be used in many places, such as chemical industry, smart public toilets, automobile industry, breeding places, atmospheric monitoring, water quality monitoring and environmental protection.



Fully functional, excellent performance, wide application, and can meet the needs of ammonia monitoring in many scenarios.



Technical Parameters

Power Supply

5~28VDC

Weight

120g

Operating Emperature

-20℃~60℃

Measuring Principle

Electrochemistry

 Lifespan

<2 years



Measuring Range



NH3:0~50 ppm

Temp:-40~+80 ℃

Humi:0~99.9 %RH

Frequency

CN470/IN865/EU868/RU864/US915/AU915/



KR920/AS923-1&2&3&4

Mode

OTAA  Class A/C(Default: Class C)

Reporting cycle

External power supply:5min(Default reporting cycle)

Report after preheating for 3 minutes when powered on

Communication Protocol

LoRaWAN,LoRa TDMA Networking

Equipment information

(Reference)

AppEUI:0000000000000001

DevEUI:aaaa202404150001

AppKey:00001111222233334444555566667777

MAC Version:LoRaWAN 1.0.3

Product Applications

1. Chemical industry: Real time monitoring and control of ammonia concentration to prevent environmental pollution and worker safety risks.
2. Smart public toilet: Real time monitoring of ammonia concentration in the toilet can clean the toilet in a timely manner, improve hygiene conditions, and enhance user experience.
3. Breeding industry: Ammonia sensors are used in breeding farms to monitor the concentration of ammonia in the environment and prevent high concentrations of ammonia from harming the health of animals and workers.
4. Atmospheric monitoring: Ammonia gas sensors are used to monitor the concentration of ammonia in the atmosphere, evaluate air quality, and provide data support for environmental protection.
5. Environmental protection: In the field of environmental protection, ammonia gas sensors are used to monitor and treat ammonia gas and ammonia nitrogen in industrial wastewater and landfill leachate, to prevent pollution of groundwater and surrounding ecological environment.

Detailed Images



Common knowledge of  NH3



Does ammonia have a smell

Yes, ammonia has a strong irritating odor. In common fertilizers and toilet cleaners in life, if ammonia contains it, it can be smelled when volatile.



What is the use of ammonia in industry

It is widely used in the manufacture of fertilizers, is also used in the production of nitric acid, refrigerants, and is also an important raw material in pharmaceutical, plastic, synthetic fiber and other industries.



Why use ammonia sensors

Because ammonia leakage is very harmful, the use of ammonia sensor can monitor the concentration of ammonia in the environment in real time, and once it exceeds the standard, thereby preventing accidents such as poisoning and explosion, ensuring the safety of personnel and the normal conduct of production.



Application Scenarios

Industrial production

Waste gas emission monitoring: Conduct real-time monitoring of industrial waste gas emissions to ensure that waste gases meet emission standards and reduce pollution to the environment.



Environmental inspection

Air quality monitoring helps people understand air quality and protect the environment and health by detecting harmful gases such as sulfur dioxide.

Safety protection

In coal mines and tunnels, gas sensors detect toxic and harmful gases such as methane and warn against accidents.



FAQ
1.Are you manufacture?
A:Yes,we are Tranmitter manufacturer and exporter in China with more than 10 years of CE,ROHS,FCC,ISO and 11 patents experience.

2.Do you offer OEM services?

A:Yes,we can provide you with OEM services and design housings and logos.



3.DO you offer free samples?



A:Sorry,we don't offer free samples. After ordering in bulk, we will deduct the sample fee from the second order.



Why Choose ZONEWU

  • Professional IoT Sensor Manufacturer
    Specializes in R&D, production, and sales of IoT sensors with strong technical expertise
  • High Quality and Reliability
    Products certified with international standards (e.g., CE, RoHS), ensuring high quality and long lifespan.
  • Wide Range of Applications
    Products serve diverse industries such as water quality monitoring, environmental monitoring, and industrial automation, offering strong market adaptability.
  • Advanced Technology
    Utilizes cutting-edge communication technologies like LoRaWAN and NB-IoT for remote, low-power data transmission.
  • Customized Solutions
    Provides tailored products and OEM/ODM services to meet diverse application needs.
