xiamen ZoneWu LoRaWAN CO2 monitor is a new type of wireless gas sensing device developed based on LoRaTM spread spectrum modulation technology. Its built-in carbon dioxide and temperature and humidity sensors can accurately measure the carbon dioxide concentration, temperature and humidity data in the environment in real time. The monitoring instrument has the characteristics of high sensitivity, high resolution and fast response. It is not only durable and supports temperature compensation, but also has the significant advantage of stable output.
Product Model :
LW303-CO2Power Supply Mode :
Battery or External DCFrequency :
CN470/IN865/EU868/RU864/US915/AU915/ KR920/AS923-1&2&3&4MAC Version :
LoRaWAN 1.0.3Mode :
OTAA Class A/CWeight :
120gNew Type LoRaWAN Wireless CO2 Detector
xiamen ZoneWu LoRaWAN CO2 monitor instrument has outstanding functions, which can collect carbon dioxide data in the environment, track its concentration changes in real time, and complete data transmission. As a wireless gas sensor, it performs well.
xiamen ZoneWu LoRaWAN Gas Sensor CO2 Sensor Features:
The LoRaWAN CO2 monitor uses the principle of non-dispersive infrared (NDIR) to detect carbon dioxide in the air. Simply put, it is using specific infrared technology to detect the amount of carbon dioxide without relying on oxygen.
The performance is very stable, it is not easy to fail, and the service life is long, it does not need to be replaced frequently, which can help everyone save a lot of trouble.
It has a built-in temperature compensation function, which ensures that the test results are accurate no matter how the ambient temperature changes, and does not affect the data because of temperature.
It supports the standard LoRaWAN protocol and can realize long-distance wireless communication. Even if the monitor and the device receiving the data are far away, the detected data can be transmitted steadily.
In the HVAC system, it can monitor indoor carbon dioxide concentration in real time, help regulate ventilation, and ensure indoor air quality, so that everyone can live comfortably and healthily.
In industrial production, it can monitor the production environment and ensure safety; In agriculture and animal husbandry production, it can regulate the gas environment in the greenhouse or breeding house, helping to promote the healthy growth of plants and animals.
Product Parameters
|
Power Supply |
5~28VDC |
|
Weight |
120g |
|
Operating Emperature |
-20℃～60℃ |
|
Measuring Principle |
Principle of Non Dispersive Infrared (NDIR) |
|
Measuring Range
|
CO2:0～5% Vol |
|
Temp:-40~+80 ℃ |
|
|
Humi:0~99.9 %RH |
|
|
Resolution Ratio |
CH4:1%Vol |
|
Lifespan |
> 5 years |
|
Frequency |
CN470/IN865/EU868/RU864/US915/AU915/ KR920/AS923-1&2&3&4 |
|
Mode |
OTAA Class A/C(Default: Class C) |
|
Reporting cycle |
External power supply:10min(Default reporting cycle) |
|
Communication Protocol |
LoRaWAN,LoRa TDMA Networking |
|
Equipment information (Reference) |
AppEUI：331341E186891989 DevEUI：aaaa202404150001 AppKey：5572404c696e6b4c6f526132330313823 MAC Version：LoRaWAN 1.0.3 |
Product Applications
1. In the industrial field： it can detect the concentration of carbon dioxide in confined spaces (such as underground mines, warehouses, etc.) to prevent suffocation accidents.
2. Environmental protection and monitoring: CO2 sensors are used to track and analyze changes in CO2 in the atmosphere, providing data support for controlling greenhouse gases. Helps evaluate air quality and provides health guidance for the public.
3. Agricultural applications: In the field of agriculture, CO2 sensors are used to monitor the concentration of CO2 in greenhouses to optimize crop growth environments and increase crop yields. In addition, monitoring the concentration of carbon dioxide is used to control the air quality inside the house and ensure animal health.
4. Smart Home and Building Automation: Improving Indoor Air Quality and Enhancing Quality of Life. Realize energy conservation and emission reduction.
Detailed Images
Common knowledge of CO2
What are carbon dioxide sensors for
It is mainly used to detect the concentration of carbon dioxide in the air, such as indoor air quality monitoring, industrial production control, and greenhouse environmental regulation, all of which depend on it, and it is important to safeguard the environment and production.
What does a carbon dioxide sensor do
It is common to use the principle of infrared absorption. Carbon dioxide molecules absorb specific wavelengths of infrared light. By detecting the change in the intensity of the infrared light, the concentration of carbon dioxide can be calculated. There is also the principle of electrochemistry, carbon dioxide reacts with the electrode to produce an electric current, and the concentration is determined according to the size of the current.
What are the types of carbon dioxide sensors
There are mainly non-dispersive infrared (NDIR) sensors, which have high precision, long life and low power consumption. There are also electrochemical sensors with high sensitivity, which are useful in low concentration gas detection; In addition, laser absorbing sensor resolution and accuracy are extremely high.
How often does the carbon dioxide sensor be calibrated
It is generally recommended to calibrate once every six months to a year, but if the use environment is complex and frequent detection, the calibration cycle must be shortened appropriately to ensure the accuracy of the data.
Application Scenarios
Industrial production
Waste gas emission monitoring: Conduct real-time monitoring of industrial waste gas emissions to ensure that waste gases meet emission standards and reduce pollution to the environment.
Environmental inspection
Air quality monitoring helps people understand air quality and protect the environment and health by detecting harmful gases such as sulfur dioxide.
Safety protection
In coal mines and tunnels, gas sensors detect toxic and harmful gases such as methane and warn against accidents.
