Product Model :
C-typePower Supply Mode :
10-30 VDCInterface :
RS485Protocol :
ModBus-RTU| DC Power Supply (default) | 10-30VDC | |
| Maximum Power Consumption | RS485 output | 0.8W |
| Range | Wind Speed | 0~70m/s |
| Wind Direction | 8 indication directions | |
| Humidity | 0%RH~99%RH | |
| Temperature | -40℃~+80℃ | |
| Atmospheric Pressure | 0-120kPa | |
| Noise | 30dB~120dB | |
| PM10 PM2.5 | 0-1000μg/m³ | |
| CO2 | 0-5000ppm | |
| Accuracy | Wind Speed | ± (0.2+0.03V) m/s V represents wind speed (60% RH, 25 ℃) |
| Wind Direction | - | |
| Humidity | ±3%RH(60%RH,25℃) | |
| Temperature | ±0.5℃（25℃） | |
| Atmospheric Pressure | ±0.15kPa@25℃ 101kPa | |
| Noise | ± 0.5dB (at reference pitch, 94dB@1kHz ） | |
| PM10 PM2.5 |
Particle counting efficiency: 50% @ 0.3 μ m, 98% @>=0.5 μ m. PM2.5 accuracy: ± 3% FS (@ 0~100 μ g/m3, 25 ℃, 50% RH) |
|
| CO2 | ±(50ppm+ 3%F·S) (25℃) | |
| Output Signal | RS485 | RS485 (Standard ModBus Communication Protocol) |
xiamen ZoneWu LoRa soil pH sensor is a wireless IoT sensor developed based on LoRa technology, Utilizing electrochemical principles for measurement, it has the characteristics of precise measurement, rapid response, and stable output, which can meet the detection needs of various soil types, and supports the standard LoRaWAN protocol to complete remote wireless data interaction.
Details
xiamen ZoneWu Wireless LoRa Soil Electrical Conductivity Sensor is an integrated wireless IoT sensor with high sensitivity and stable performance. It is based on the measurement principle of soil dielectric constant, can intuitively and stably reflect the real water content of various types of soil, can accurately measure the volume percentage of soil moisture, and adopts the soil moisture measurement method in line with the current international standards. The sensor supports the standard LoRaWAN protocol, enabling wireless remote data communication.
Details
xiamen ZoneWu LoRa Soil Nitrogen, Phosphorus, and Potassium (NPK) Sensor is an innovative wireless sensing device, which has the functions of collection, monitoring and transmission, and can real-time accurately monitor the content of nitrogen, phosphorus and potassium in the soil, with high measurement accuracy. The LoRWAN collector is connected to the sensor via an aviation connector, and the connection operation is quick and convenient. It follows the standard LoRaWAN protocol, enabling long-distance data transmission.
