Our integrated shutter box sensor can be widely used for environmental detection, integrated noise collection, PM2.5 and PM10, temperature and humidity, atmospheric pressure and illumination. It is installed in the louver box. The device adopts standard MODBUS-RTU communication protocol and RS485 The transmitter is widely used in various occasions such as measuring ambient temperature and humidity, noise, air quality, atmospheric pressure and illumination, etc. It is safe and reliable, Beautiful in appearance, convenient to install and durable.
Product Model :
ZW-BYHPower Supply Mode :
10-30VDCWeight :
2kgInterface :
RS485Protocol :
ModBusRTUHot-sale Louver Box Noise Transmitter
The Louver box noise transmitter is a specialized device for noise - related detection. In terms of functions, it can accurately measure the sound intensity and frequency, as well as monitor the amplitude and frequency of vibrations. It also has a signal - conversion function, transforming sound and vibration signals into electrical signals for subsequent digital processing and analysis. Regarding applications, in the industrial field, it is used to analyze the noise generated by machinery and electronic equipment, helping to determine whether the equipment is operating normally. In environmental monitoring, it can monitor the noise in urban functional areas, traffic roads, and regional environments, providing basic data for noise - pollution planning, management, and comprehensive improvement. Additionally, in places with high requirements for acoustic environments, such as concert halls and recording studios, it can be used to monitor the ambient noise level.
Technical Parameter
|
DC power supply |
10-30VDC |
|
|
Maximum power consumption |
RS485Output |
0.8W |
|
Measure Range |
Temperature |
-40℃~+80℃ |
|
Humidity |
0%RH~99%RH |
|
|
Illumination |
0~20WLux |
|
|
Atmospheric pressure |
0-120Kpa |
|
|
Noise |
30dB~120dB |
|
|
PM10 PM2.5 |
0-1000ug/m3 |
|
|
CO2 |
0-5000ppm |
|
|
Accuracy |
Temperature |
±0.5℃（25℃） |
|
Humidity |
± 3% RH (60% RH, 25 ℃) |
|
|
Illumination |
±7%(25℃) |
|
|
Atmospheric pressure |
±0.15Kpa@25℃ 101Kpa |
|
|
Noise |
±0.5dB |
|
|
PM10 PM2.5 |
±3%FS(@100μg/m3,25℃,50%RH) |
|
|
CO2 |
±(50ppm+ 3%F·S) (25℃) |
|
|
Long-term stability |
Temperature |
≤0.1℃/y |
|
Humidity |
≤1%/y |
|
|
Illumination |
≤5%/y |
|
|
Atmospheric pressure |
-0.1Kpa/y |
|
|
Noise |
≤3db/y |
|
|
PM10 PM2.5 |
≤1ug/m3/y |
|
|
CO2 |
≤30ppm/y |
|
